SECTION VIIA TECH 2 MAIN MENU & LIVE PLOT
2005 Tech 2 User’s Guide VII - 11
Figure VIIA-13
Getting Started selected on Main Menu
Getting Started
Selecting Getting Started from the Tech 2 Main Menu (Figure VIIA-13) reveals the Getting Started Menu
(Figure VIIA-14), which provides an on-line overview of the Tech 2 and useful operation information.
The following options are available from the Getting Started Menu.
F0: Tool Controls - Selecting an option from the Tool Controls Menu (Figure VIIA-15) will give you
information on Tech 2 help functions, key pad layout, screen contrast control, and soft keys.
F1: Hardware - The Hardware Menu (Figure VIIA-16) offers information on screen display, VCI module
removal, PCMCIA card removal and installation, cables/adapters and power connections, prop rod and
hand straps, and RS-232 and RS-485 ports.
F2: Tech 2 Features - This selection displays a vehicle information entry sequence for a fictitious vehicle
(Figure VIIA-17).
F3: Programming Tech 2 - This option provides instructions for downloading from a PC to the Tech 2
scan tool. Due to a specific sequence of events in the evolution of the Tech 2, this option duplicates the
Programming Tech 2 function of the Tool Options Menu, as described on page VII-9.
Figure VIIA-15
Tool Controls Menu
Figure VIIA-14
Getting Started Menu
Figure VIIA-16
Hardware Menu
Figure VIIA-17
Tech 2 Features screen
