SECTION VIIA TECH 2 MAIN MENU & LIVE PLOT
2005 Tech 2 User’s Guide VII - 10
Figure VIIA-11
PCMCIA Card Duplicator screen displaying card data for both Tech 2 slots
F7: Make Duplicate PCMCIA Card
After you select the F7: Make Duplicate PCMCIA Card option, which enables you to duplicate current
PCMCIA card data, the display will ask you to insert the destination card (the PCMCIA card that you want
to update) into the open PCMCIA card slot, then press [ENTER] to continue. The PCMCIA Card Duplicator
screen (Figure VIIA-11) will appear, showing the current version of both cards. The highlighted areas on
the screen represent the locations of the source and destination PCMCIA cards, and the arrows indicate
the direction of the data flow. Slot 1 is defined as the slot closest to the Tech 2 display. Use the Copy soft
key to initiate the duplication process.
If the card capacity is too small (less than 32 megabytes), a screen like the one shown in Figure VIIA-12
will appear. Insert a 32-megabyte PCMCIA card to resolve the problem.
F8: Set Language
The F8: Set Language option enables you to set your language preference.
F9: CANdi Diagnostics
When you select F9: CANdi Diagnostics (a function limited to certain vehicles), the CANdi Diagnostics
screen (Figure VI-30) appears and you may perform a complete diagnosis of the CANdi module.
Refer to Section VI and Section VIID for more detail on CANdi diagnostics.
Figure VIIA-12
PCMCIA Card Duplicator screen displaying “Card Too Small” message
