SECTION VIIA TECH 2 MAIN MENU & LIVE PLOT
2005 Tech 2 User’s Guide VII - 9
Figure VIIA-8
Set Training Center Mode screen
F5: Programming Tech 2
After you select F5: Programming Tech 2, you can follow the on-screen instructions (Figure VIIA-9) for
downloading from a PC to the Tech 2 scan tool via the RS-232 cable. Refer also to Software Download,
Tech 2 PCMCIA Card, and Tech 2 Update Procedure later in this section.
Figure VIIA-9
Programming Tech 2 screen
Figure VIIA-10
Set Communication By-Pass Mode screen
Tool Options continued on next page...
F4: Set Training Center Mode
After you select F4: Set Training Center Mode—for GM Training Centers only—a Set Training Center
Mode screen appears (Figure VIIA-8), giving you the ability to connect multiple Tech 2 scan tools for
instructional purposes.
F6: Set Communication By-Pass Mode
When you select F6: Set Communication By-Pass Mode, the upcoming screen (Figure VIIA-10) offers
Disable and Enable options. By enabling the by-pass mode, the Tech 2 bypasses error handling and
allows the user to view data display information without being connected to a vehicle. Highlight the desired
setting using the up or down arrow keys, then press [ENTER] to change the current mode. The Tech 2 will
default to the Disable mode after it has been powered off.
