SECTION VIIB TIS SOFTWARE
2005 Tech 2 User’s Guide VII - 23
Uploading the Snapshot to the PC
After a snapshot has been successfully captured, perform the following steps to upload it from the scan
tool to the computer.
1. Launch TIS.
2. Select Snapshot Upload/Display from the TIS main screen (Figure VIIB-2).
3. Select the “Upload from Handheld” box in the center of the screen (Figure VIIB-13),
or select the
Upload from Handheld icon on the Snapshot toolbar (refer to Figure VIIB-15).
4. Select Tech 2 on the “Upload from a Handheld Device” window, verify that the Tech 2 is connected to
the terminal, and then select OK (Figure VIIB-14).
5. Select the snapshot to be uploaded, then select OK.
6. After the snapshot uploads, a list of data parameters will display on the monitor (Figure VIIB-15).
For instructions on viewing a snapshot after it has been uploaded, refer to the next page.
Figure VIIB-13
“Upload from Handheld” option shown on Snapshot Upload/Display screen
Figure VIIB-14
On-screen instructions for uploading from a handheld device
Figure VIIB-15
Snapshot Upload/Display screen (two-column mode) with toolbar and playback details defined
