SECTION VIIB TIS SOFTWARE
2005 Tech 2 User’s Guide VII - 24
Viewing the Snapshot
After a snapshot has been uploaded (either from disk or the scan tool), it can be viewed and analyzed in a
variety of ways. Figure VIIB-15 identifies the different display icons and replay selections.
Replaying the Snapshot
To replay a snapshot, use the row of icons in the lower left-hand corner of the screen (see Figure VIIB-15).
The selections and their functions are as follows:
• First Frame. Displays the first frame of the snapshot, regardless of which frame was displayed prior to
selection.
• Reverse One Frame. Displays the frame immediately preceding the one currently displayed.
• Play in Reverse. Causes the snapshot to continuously play in reverse until the first frame is displayed.
• Trigger Frame. Causes the display to move to the exact frame when the snapshot was triggered,
regardless of which frame was displayed before the item was selected.
• Play Forward. Causes the snapshot to continuously play forward until the last frame is reached.
• Forward One Frame. Moves the snapshot forward to the next frame.
• Last Frame. Displays the last frame in the snapshot.
• Stop Play. Stops a continuous play snapshot at the frame displayed at the time of selection.
