GMP PROTOPIC III-540 - Paper Table and Belt Tension Adjustment

MAIN DEVICES
☞ Paper Table
For convenient lamination job. Substrates can be put on the table.
Pull the table handle to draw the table out.
☞ Tension Adjustment of Conveyor Belt
Long time operation could make conveyor belt loosen.
If the belt is loosen, feeding could not be working properly.
Adjust its tension with Tension Adjustment Bolts that are at Feed Table.
Turn it to the right to increase tension and turn it to the left to decrease it.
(Adjust it with 5mm Wrench that is packed in the machine.)
NOTE : Cover has to be removed to adjust it.
Tension Adjustment Bolt
25/48
