TROUBLE SHOOTING
Trouble Type Reason How to solve
Laminating Roller 1. Safety Switch on the Laminating roller cover is open. 1. Close laminating roller cover safety switch.
does not work.
2. Laminating roller motor is broken OR 2. Contact our dealer or A/S center.
Timing belt is damaged.
3. Fuse disconnection 3. Exchange the enclosed fuse.
Feeding interval is irregular
1. Paper length setting is wrong.
1. Using "LENGTH" button on control panel, set the right paper length
Explanation on the function button, refer to the function button "LENGTH"
2. Irregular paper size.
2. Use the standard size paper
No feeding 1. The edge of paper conflict with the feeder 1. Spread the paper rightly and laminate
2. Paper is conveyed on only just two lines
2. Necessarily check the paper is conveyed with more than 3 lines.
Feeding paper array is not 1. Paper loading is not good on the feeding table. 1. Use paper guide
good. 2. Conveyer belt tension is not good 2. Adjust the tension using conveyer belt tension control bolt.
Refer to the laminating part "Conveyer belt tension control"
3. Paper guide status is not right
During operating, a sudden 1. Emergency switch is pressed 1. Unlock the emergency switch
stop
Refer to other device "Emergency Switch"
2. By the feeding errors, front/rear paper feeding interval
2. Using "LOADING" button, feed the new paper
is larger, system stops
Refer to each button "LOADING"
Feeding
