SPECIFICATION
ITEMS PROTOPIC III - 540 PROTOPIC III - 540 DUAL
Dimension(W*L*H)(mm)
800*1580*670(1340 - incl. Lami Table height) 800*1820*670(1340 - incl. Lami Table height)
Max. Laminating Speed(m/min) 15 15
Max. Paper Size(mm) 540*800 540*800
Min. Paper Size(mm) 210*203 210*203
Substrate Thickness(g/㎡) 120~350 120~350
Laminating Film
POLYNEX,PERFEX,NYLONEX FILM (20~44㎛)
POLYNEX,PERFEX,NYLONEX FILM (20~44㎛)
Rated Voltage AC 220~240V/12A
AC 220~240V/14A
Power Consumption
2.8 kw
3.45 kw
Warm-up Time
7 mins.
7 mins.
Heating System
INFRARED HEATER
INFRARED HEATER
Roller Temperature(℃)
MAX.150 MAX.150
Temp. Control JOG DIAL JOG DIAL
Speed Control JOG DIAL JOG DIAL
Bursting Motor
DC MOTOR
DC MOTOR
Roller Pressure System
Pneumatic Cylinder Pneumatic Cylinder
Film Core
77MM(3") DUAL
77MM(3") DUAL
Cooling Motor BLOWER BLOWER
Cutting System BURST CUTTING WITH PERFORATOR BURST CUTTING WITH PERFORATOR
※ External Design & Specification could be changed without any prior notice for improvement.
