8. Installation
5.
The go-e Charger is equipped with an integra-
ted RCD protection module with direct current
detection (20 mA AC, 6 mA DC).
Only a type A RCD is required on the building
side, unless local regulations deviate from this.
In addition, a miniature circuit breaker must be
installed upstream.
Miniature circuit breakers with characteristic B
or C for 16 or 32 amperes are permissible:
• 3- or 4-pole for three-phase connection
• 2-pole for single-phase connection
6.
The go-e Charger Gemini may be connected sin-
gle-phase and three-phase. If necessary, lay an
additional supply line. When selecting the cable
cross-section, observe the simultaneity factor
and the type of installation. We recommend the
following cable cross-sections, but the electri-
cian has to decide according to local conditions:
Gemini 11 kW Gemini 22 kW
as surface-
mounted
at least 2.5 mm² at least 6 mm²
in wall
at least 4 mm² at least 6-10
mm²
in insulation at least 10 mm² at least 10 mm²
The connection cable of the go-e Charger Ge-
mini may also be shortened. Connection via a
junction box is possible.
