Page 6
Chapter 4, Main Frame
Washer
2.1x
4.5x0.5mm
[H0566]
Socket Head Cap
Screw M2x8mm
(HC008-S)
Socket Head Cap
Screw M2x8mm
(HC008-S)
Washer
2.1x
4.5x0.5mm
[H0566]
Landing Gear
(H0799-S)
Socket Head Cap
Screw M2x10mm
(HC010-S)
Landing Gear Assembly
BAG 1
