Goblin FIREBALL - Chapter 6, Installation Of The Boom; Main Frame and Tail Boom Integration; Carbon Rod Installation

CC
Page 10
Chapter 6, Installation Of The Boom
Main Frame Assembly
Carbon Rod
Assembly
Unscrew the M2.5x8mm screw shown in the picture.
Insert the belt and the boom.
Push until you hear the boom "click” into the frame.
Tighten the M2.5x8mm screw.
Tail Boom
Assembly
" Click "
Install the carbon rod
