Godex DT2x - Loading the Label Roll

9
DT2 / DT4 series User Manual
2. Printer setup
2-1. Loading the label roll
1.
Place the printer on a
flat surface and open
the printer cover.
2. Release the label
supply hub.
3.
Lift the label roll
holder and pull it out
as far as possible.
4. Install the label roll on
the label supply hub.
5.
Now press the label
roll holder down until
it clicks into place.
6. Return the label roll
holder to its original
position.
