Godex DT2x - Installing the Cutter Module

29
DT2 / DT4 series User Manual
5-2. Installing the cutter
1
Cutter module
2 Screws (set of 2)
【
Important
】
Remember to switch off the
printer before installing the
cutter.
【 Note 1 】
Do not use to cut adhesive
labels! Glue residue will be
left on the cutter blade and
impair its functioning. The
cutter has a blade life of
1,000,000 cuts when using
paper weighing up to
120 g/m² and 500,000 cuts
when using paper weighing
between 120 g and 170
g/m².
【
Note 2
】
You can cut paper with a max. width of 114 mm.
【 Note 3 】
Labels should be at least 30 mm high (DT4).
(DT2: 40 mm)
【 Suggestion 】
During installation of the cutter, set the stop position in
Qlabel and/or in the driver to 30.
1. Place the printer on a
flat surface and open
the printer cover.
2. Remove the front cover.
2
1
