30
DT2 / DT4 series User Manual
3. Pass the cutter cable
through the opening as
shown in the illustration.
4. Fit the label cutter in the
recess provided.
DT4
DT2
5.
Turn the
printer
upside
down and
tighten the
screws to
secure the
cutter.
5.
Turn the
printer
upside down
and remove
the screw
that secures
the cover on
the bottom
of the
printer.
6.
Open the
cover on
the bottom
of the
printer to
access the
motherboar
d
.
6.
Tighten the
screws to
secure the
label cutter.
7. Connect the cutter to
the motherboard.
【 Note 】
Please make sure that you
are using the correct
connector.
