Printer Setup
2.4 Loading The Label Roll
A New Label Roll Module Installation
LABEL STOCK LABEL SUPPLY HUB
1. Place the label stock on the label supply hub, attach the label guide plates to the label stock holder.
Place on the ribbon hub
2. A label roll module is assembled as below.
A NEW LABEL ROLL MODULE
