2 Printer Setup
008
Load the Ribbon on the Printer
For Ribbon Supply Module
RIBBON SUPPLY MECHANISM
NOTCH OF RIBBON SUPPLY WHEEL
RIBBON SUPPLY WHEEL
Place
RIBBON SUPPLY
MODULE
1. Place the ribbon supply module into the printing mechanism. Please the left-hand side of ribbon hub first.
Make sure the holder of ribbon hub is inserted into the notch. Then place the right-hand side of ribbon hub.
放入
Left side
HOLDER
NOTCH OF
RIBBON SUPPLY WHEEL
Place
Right side
HOLDER
Place
NOTCH
