5 Accessories
051
3. The feeding path of label and liner should be as shown in below graphic.
4. Close the label dispenser and printer cover. The installation is completed now.
LABEL STOCK
PLATEN
ROLLER
LABEL
LABEL LINER
RT700i
Close the cover
