38
5 Accessories
050
2. Feed the Label stock through the label guides.
And pull the label liner through the platen and the steel of the label dispenser.
****Labels should be at least 25 mm high.
Loading Label Roll with the Label Dispenser Module
1. Remove the first label from the label stock.
Tear a label
THE FIRST LABEL
LABEL STOCK
LABEL LINER
Through the label guides
LABEL LINER
PLATEN
Through the platen
and the steel
STEEL
