GOK SmartBox 4 - Page 18

SmartBox
®
4 / SmartBox
®
4 PRO
18 / 28 part no. 28 400 57 d
Menu
Setting
Description
17.Input/
Output
Alarm-In 
Sets the function of the alarm contact input
Closing
Closer alarm. Input closed  Alarm
Opening
Opener alarm. Input contact opens  Alarm
Deactiv
Sets the alarm input functionless
Data-Out

Defines the data output on the output adapter slot
Tank: 1
1-4
For data output a selection can be made between
• Output single tank 1, 2, 3 or 4  for analogue
adapter
• Output “1-4”  all tanks are output sequentially
 via digital slot-in adapter – e.g. for H-Box
17b.
H protocol
Data output:
Deactiv
Data: Litres
Data: Level
Data output to H Box (only with DTM-2):
• Deactivated
• Output in litres
• Output in level
18.Language
Names
Language:
German, English, French, Spain
[+] / [-] / [Enter]
Names:
ESC [+] / [-] / [Enter]
Name Tank 1: Suggested name
Letters can be changed with [+] / [-] / [Enter]
19.Exit
Back to display mode
20.LCD
display
Contrast: 90
Set the contrast of the LCD display
21.Device
info
Displays information about
Software version: V7.00 (e. g.)
Serial number: Tank 1: SN=1234 (e. g.)
Offset+Gain:X0=4.05mA B=1268 (Tank 1)
22.Test
current
Test function for the current mA value of the
probe: ADC = 28A0 = 04.00mA
If level probe is not submerged, the value should
be close to 4 mA. Tolerance range is 3.7 ... 4.3
mA. For larger deviations, see menu item 9.
23.Test
relay
 SmartBox
4
Furthermore, devices connected on the relay contact will
also be switched on and/or off!
• Connected devices can be damaged (dry running).
• Operating media may leak.
Disconnect the devices connected before test relay.
Only reconnect the devices again after test relay.
Relay 1 ON/OFF
Test function for the switch function of relay
24.Reset
ESC
Exit this function without executing it.
Restart
Initialisation. The device software restarts and
keeps all device settings.
Factory settings
Complete reset of all parameters to the original
delivery status.
26.Exit
[Enter] back to display mode.
