PROGRAMMING
Overfilling of the tank due to incorrect entry values.
Operating media may leak. These:
• are hazardous to water,
• are category 1,2 and 3 inflammable liquids,
• can ignite and cause burning,
• may cause falling injuries due to slipping.
Enter these values with care!
The entry values are also retained in the event of the failure of the supply voltage.
Programming the level gauge
Before progr
amming, you need to ascertain the tank data and enter the values into the right
column (Input value) of the following table. Then, enter the values for the individual entry
steps.
Setting a
parameter:
Press [ENTER] to open setup mode.
Select the desired setting parameter via [PLUS].
Press [ENTER] to call up the value selection for the parameter.
Set the value with [MINUS]/[PLUS], press [ENTER] to save.
Quitting the
setup mode:
You can quit the setup mode at any time.
Select “Exit“ and press [ENTER]
 to go back to the standard display mode.
Menu
Input function
Input value
Tank: 1
 SmartBox
4
PRO
Select the tank (tank: 1 to tank: 4) to enter the
corresponding values. (This step is not displayed if
only one probe is connected to SmartBox
®
4 PRO.)
Tank:_______
0.Exit
Press [ENTER] to return to display mode
1.Measure
probe
Select probe measuring range see type label of the
probe - default setting 250 mbar
______mbar
Standard probe
max. tank height for
fuel oil
water
100mbar
1.20m
1.00m
150mbar
1.80m
1.50m
160mbar
1.90m
1.60m
200mbar
2.40m
2.00m
250mbar
2.90m
2.50m
400mbar
4.70m
4.00m
500mbar
6.00m
5.00m
1.000mbar
12.00m
10.00m
2.000mbar
24.00m
20.00m
3.000mbar
36.00m
30.00m
5.000mbar
60.00m
50.00m
set mbar
