VERTICALLYWITHNEWCHIMNEYSYSTEM

(RefertoFigure7)



OPTION:Toachieveacenterverticalinstallationa

45ºelbowandaclean‐outteecanbeusedtooffset

thepipefromtheexhaustoutlettotherearcenterof

thestove.



OPTION:InstallL‐Ventelbowinplaceofclean‐out

tee.Locatestove.Dropplumbbobtocenteroftee

outlet,markpointonceiling.Installceilingsupport

andL‐VentpipeperL‐Ventmanufacturer’s

instructions.



1. Alwaysmaintain3”clearancefromcombustible

materials.Whenpassingthroughadditionalfloors

orceilings,alwaysinstallfirestopspacer.



2. Afterliningupforholeinroof,cuteitheraround

orsquareholeinroof,always3”largeralltheway

aroundpipe.Installupperedgeandsidesof

flashingunderroofingmaterials,nailtotheroofalongupperedge.Donotnailloweredge.Seal

nailheadswithnon‐hardeningwaterproofmastic.



3. Applynon‐hardening,waterproofmasticwherethestormcollarwillmeettheventandflashing.

Slidestormcollardownuntilitsitsontheflashing.Sealandinstallcap.Mobilehomeinstallations

mustuseasparkarrester.



VERTICALLYINTOEXISTINGCHIMNEYSYSTEM

Ifyouhaveandexistingchimneysystemyoucanrunyournew

L‐Ventpipeupthroughthecenterofyourexistingchimney

system.(refertofigure8)



Followguidelinesforequivalentventlength.



FOLLOWYOURVENTPIPEMANUFACTURERS

INSTRUCTIONSREGARDINGALLASPECTSOFVENT

INSTALLATIONANDCLEARANCES.





Figure7
