Buzzaround_SG_REVA_040711
36
Front body assembly (SB05E101)
ITEM PART NO. DESCRIPTION QTY
01 SB05E201
Tiller, Complete Assembly not including Colored Plastic for
Buzz GB106 January 2010
1
02 SB3P132A Knob label 1
03 SB3A501A T the knob 1
04 SB3E503A Pedal pad set 1
05 SB3P501A Head tube sheath Paint 1
06 3111704011 Cross trough with meson drilling screw (white zinc plated) 4
07 SB3E504A Front Body Section 1
08 SA2P001A Compression spring (white nickel-plated) 1
09 3110410452 Hex bolts (black zinc-plated) 1
10 SB05E103 Front frame assembly 1
11 SB3P136A Bottom label 1
To Next Page
