Buzzaround_SG_REVA_040711
42
05 WC9P453A Square tube plug 32 * 32 * 2.5 (black) 1
06 3111308010 Star Bolt M8 * 20L 1
07 3000406032 Flat washer Ø8.4 * Ø24 * 2 (white zinc plated) 4
08 3003108011 Spring washer Ø8 (white zinc plated) 4
09 3110408081 Hex bolts M8 * 25 (white zinc plated) 4
10 SE1E403B Block Pallet Assembly 1
11 SB05E402
Arm, Assembly Right for LiteRider GL110 and Buzz GB106 January
2010
1
12 WC9P401A Handrail locking hand wheel 2
Right Arm Assembly (SB05E402)
ITEM PART NO. DESCRIPTION QTY
01 WC6A405A
Pad, Arm for LiteRider GL110, Buzz GB106 and Buzz XL
GB116
1
02 3110308072 Large flat head socket screw M8 * 30L (black zinc-plated) 1
03 3100108012 Hexagon nut M8 (black zinc-plated) 1
04 3111706052 Of the lock screw Ø8/M6 * 33L (black zinc-plated) 1
05 WC6A401A Right arm group 1
06 3110106032 Large flat head socket screw M6 * 12L (black zinc-plated) 3
To Next Page
