Seat Swivel Assembly (SE1E403B)
ITEM PART NO. DESCRIPTION QTY
01 SE1A401B Seat bottom group Electric black 1
02 3000608012 Rolling pin spring Ф 8 * 63.5 (black zinc-plated) 1
03 3030108010 Lever sleeve 1
04 SE1A404B Seat lock handle set Electric black 1
05 SE1P413B Limit set 1
06 SA2P416A Double torsion spring φ 2.5 (black zinc-plated) 1
07 WC9P453A 32 Cyprus 32 * 32 * 2.5 1
08 SE1P529A Annex frame tube labels 62 * 25 1
Seat Tube Assembly (SB3E410A)
ITEM PART NO. DESCRIPTION QTY
01 SB3A407A Seat tube White zinc-plated 1
02 SA2P419A Seat tube bushing Black 1
03 3000604022 Spring pin (straight groove) Ø4 * 6L (black zinc-plated) 1
