Buzzaround_SG_REVA_040711
48
Battery Box Assembly (SB3E601A)
ITEM PART NO. DESCRIPTION QTY
01 SB3E501A Combination of the battery box cover 1
02 3052512010 Battery 12V12AH 2
03 3000325020 Velcro hair surface 25 * 90 4
04 3000325010 Velcro gill surface 25 * 90 4
05 3110904021 Cross pan head tapping screws ST4.2 * 20L (white zinc plated flat tail) 4
06 SB3P516A Electrode clip holder (1) Black 2
07 SB3P601A Electrode folder Nickel 3
08 SB3A504A Under the battery box cover Black 1
09 3110903041 Cross pan head tapping screws ST3.5 * 20L (white zinc plated flat tail) 12
10 SB3P130A Iron lock Electric black 1
11 3111005041 Cross Countersunk head screws M5 * 10L (white zinc plated) 2
