Buzzaround_SG_REVA_040711
50
Front Cover Assembly (SE05E602)
ITEM PART NO. DESCRIPTION QTY
01 SE06P511 Vice-speed control knob 1
02 SE05P509 T to the black ABS panels 1
03 SB3P608A Gauge fixed film PCABS 1
04 3110103011 Large flat head cross tapping screw ST2.9 * 8 white zinc plated 2
05 SE05A601 Cover panel line group 1
06 30010902012 Cross pan head screw ST2.2 * 8 (black zinc-plated) 2
