Goodwe MS Series User Manual

21
User Manual V1.0-2022-10-30 06 Electrical Connection
WARNING
• Pay attention to the silkscreens L, N, PE on the AC terminal. Connect the AC cables to
the corresponding terminals. The inverter may be damaged if the cables are connected
inappropriately.
• Make sure that the whole cable cores are inserted into the AC terminal holes. No part of
the cable core can be exposed.
• Make sure that the cables are connected securely. Otherwise, the terminal may be too hot
to damage the inverter when the inverter is working.
Inverter model AC circuit breaker
GW700-XS
300mA
GW1000-XS
GW1500-XS
GW2000-XS
GW2500-XS
GW3000-XS
GW2500N-XS
GW3000N-XS
GW3KB-XS
GW3300-XS
GW700-XS-11
GW1000-XS-11
GW1500-XS-11
GW2000-XS-11
GW2500-XS-11
GW3000-XS-11
GW3000-XS-B11
A type A RCD(Residual Current Device) shall be added to protect the equipment when the DC
component of the leakage current exceeds limits. Recommended RCD specications:
Step 1 Make the AC output cable.
Step 2 Disassemble the DC routing hole’s end cap.
Step 3 Use the cable gland for routing wires.
Step 4 Plut the AC connector into the inverter.

Goodwe MS Series Specifications

General

Power Range	3-10 kW
MPPT	2
AC Voltage Range	180-280 V
Protection Level	IP65
Cooling Method	Natural convection
Model	MS Series
Rated Output Current	34.8 A
Operating Temperature Range	-25°C to 60°C
Communication	Wi-Fi / Ethernet
