Goodwe MS Series User Manual

40
User Manual V1.0-2022-10-30
10 Technical Parameters
10 Technical Parameters
Technical Data GW700-XS GW1000-XS GW1500-XS GW2000-XS
Input
Max. Input Power (W) 910 1,300 1,950 2,600
Max. Input Voltage (V) 500 500 500 500
MPPT Operating Voltage Range (V) 40-450 40-450 50-450 50-450
MPPT Voltage Range at Nominal
Power (V)
80-450 85-450 125-450 165-450
Start-up Voltage (V) 40 40 50 50
Nominal Input Voltage (V) 360 360 360 360
Max. Input Current per MPPT (A) 12.5 12.5 12.5 12.5
Max. Short Circuit Current per
MPPT (A)
15.6 15.6 15.6 15.6
Max. Backfeed Current to The
Array (A)
0 0 0 0
Number of MPP Trackers 1 1 1 1
Number of Strings per MPPT 1 1 1 1
Output
Nominal Output Power (W) 700 1,000 1,500 2,000
Nominal Output Apparent Power
(VA)
700 1,000 1,500 2,000
Max. AC Active Power (W)
*1
800 1,100 1,650 2,200
Max. AC Apparent Power (VA)
*2
800 1,100 1,650 2,200
Nominal Power at 40℃ (W)(Only
for Brazil)
700 1,000 1,500 2,000
Max Power at 40℃ (Including AC
Overload) (W)(Only for Brazil)
700 1,000 1,500 2,000
Nominal Output Voltage (V) 230 230 230 230
Nominal AC Grid Frequency (Hz) 50/60 50/60 50/60 50/60
Max. Output Current (A) 3.5 4.8 7.2 9.6
Max. Output Fault Current (Peak
and Duration) (A/ms)
25@5ms 25@5ms 25@5ms 25@5ms
Inrush Current (Peak and
Duration) (A/us)
50@2us 50@2us 50@2us 50@2us
Nominal Output Current (A) 3.0 4.3 6.5 8.7
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
Maximum Output Overcurrent
Protection (A)
24 24 24 24
Eciency

Goodwe MS Series Specifications

General

Power Range	3-10 kW
MPPT	2
AC Voltage Range	180-280 V
Protection Level	IP65
Cooling Method	Natural convection
Model	MS Series
Rated Output Current	34.8 A
Operating Temperature Range	-25°C to 60°C
Communication	Wi-Fi / Ethernet
