Goodwe MS Series User Manual

44
User Manual V1.0-2022-10-30
10 Technical Parameters
Technical Data GW2500N-XS GW3000N-XS GW3KB-XS GW3300-XS
Input
Max. Input Power (W) 3,250 3,900 3,900 3,900
Max. Input Voltage (V) 600 600 600 500
MPPT Operating Voltage Range (V) 50-550 50-550 50-550 50-450
MPPT Voltage Range at Nominal
Power (V)
205-450 245-450 240-450 275-450
Start-up Voltage (V) 50 50 50 50
Nominal Input Voltage (V) 360 360 360 360
Max. Input Current per MPPT (A) 13.0 13.0 13.0 12.5
Max. Short Circuit Current per MPPT
(A)
16.3 16.3 16.3 15.6
Max. Backfeed Current to The Array
(A)
0 0 0 0
Number of MPP Trackers 1 1 1 1
Number of Strings per MPPT 1 1 1 1
Output
Nominal Output Power (W) 2,500 3,000 3,000 3,300
Nominal Output Apparent Power (VA) 2,500 3,000 3,000 3,300
Max. AC Active Power (W)
*1
2,750 3,300 3,300 3,300
Max. AC Apparent Power (VA)
*2
2,750 3,300 3,300 3,300
Nominal Power at 40℃ (W)(Only for
Brazil)
2,500 3,000 3,000 3,300
Max Power at 40℃ (Including AC
Overload) (W)(Only for Brazil)
2,500 3,000 3,000 3,300
Nominal Output Voltage (V) 220/230 220/230 220 230
Nominal AC Grid Frequency (Hz) 50/60 50/60 60 50/60
Max. Output Current (A) 12.0 14.3 14.3 14.3
Max. Output Fault Current (Peak and
Duration) (A/ms)
30@5ms 30@5ms 30@5ms 30@5ms
Inrush Current (Peak and Duration)
(A/us)
50@2us 50@2us 50@2us 50@2us
Nominal Output Current (A) 11.4/10.9 13.6/13.0 13.6/13.0 14.3
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
Maximum Output Overcurrent
Protection (A)
32 32 32 32
Eciency
Max. Eciency 97.6% 97.6% 97.6% 97.6%

Goodwe MS Series Specifications

General

Power Range	3-10 kW
MPPT	2
AC Voltage Range	180-280 V
Protection Level	IP65
Cooling Method	Natural convection
Model	MS Series
Rated Output Current	34.8 A
Operating Temperature Range	-25°C to 60°C
Communication	Wi-Fi / Ethernet
