<21>
1
HFI CPU1 SIDEBAND
2
FP VGA CONN
3
FP USB3.0 CONN
4
HDD PWR3
5
GPU PWR2 (RISER1)
6
RAID KEY
7
LPC TPM
8
MINI HD SATA PORT2
9
MINI HD SATA PORT0
10
MINI HD SATA PORT1
11
MEZZCONN 0
12
MCP XDP
13
RISER1(PCIE3.0X24)
14
RS232
15
M.2 CONN
16
RISER2(PCIE3.0X24)
17
VGA
18
NMI BUTTON
19
DEDICATED LAN
20
USB2
