860-7100-19 DTU Operation Manual
ISO GRAPHICAL SYMBOLS LEGEND
(For warning labels on the Destu-it Restu-it
TM
machines)
SYMBOL OR LABEL DEFINITION
AREA SCANNER LABEL
BATTERY CHARGER
BATTERY / HOUR METER WITH SERIAL NUMBER
LIFT POINTS
TIE DOWN POINTS
CENTER OF GRAVITY POINT
E0604R1
REAR SCANNER FAULTS
(RIGHT / REVERSE / LEFT)
REVERSE SCANNER
ZERO POINT TURN RECOMMENDED
FORWARD SCANNER
FRONT SCANNER FAULTS
(RIGHT / FORWARD / LEFT)
BYPASS RECOMMENDED
L0410R2
