243912
Do not attempt to grease the telescopic retractable
guides.
After cleaning, simply replace the guide rack by following the
procedure in reverse order.
Removing wire guide racks
To facilitate cleaning of the oven interior side walls, the wire
guide rack can be removed.
• Hold the guide rack by its lower end and rotate it inwards;
then, remove them from the holes on the upper side.
• Clean the guide racks guides only with conventional cleaners.
• After cleaning, simply re-hang the guide rack in the holes
provided and pull the downwards.
REMOVING INSIDE DOOR GLASS – APPLIES TO PREMIUM
FULL-GLASS DOOR (make A and B)
Door glass can also be cleaned from the interior side; however, door
has to be removed fi rst (see section on removing and replacing the
oven door).
a)
• Hold the door glass pane by its lower edge. Pull it gently
towards yourself and lift it slightly – but not too far – by a
maximum of 10 mm, until the glass support wedge slips out of
the groove (Figure 1).
• Remove the glass (in the direction of arrow 3).
• Interior glass (only in some models) is removed by fi rst
undoing the screws on the glass supports and then by lifting
it (Figure 2). Remove the supports before cleaning the glass
pane.
• Reinstall the door by following the same procedure in reverse
order.
Note: Insert the glass into the slot and push it forward (Figure
3).
fi gure 1
fi gure 2
fi gure 3
