SWING BEAM LOADING
MAXIMUM SWING BEAM LOAD IS 425 LBS.
Weight Limits for Accessories:
The weight limit for a Swing Belt is 225 lbs. (Although 150lbs is the maximum recommended
swinging weight capacity for the swing position.)
The weight limit for a Trapeze Bar is 125 lbs.
Maximum Allowable swinging weight for a three position swing:
1) The maximum allowable swinging weight at each Swing Belt position is 150 lbs.
2) The maximum allowable swinging weight at the Trapeze position is 125 lbs.
3) The MAXIMUM SWING BEAM LOAD IS 425 lbs.
SWINGING WEIGHT
TRAPEZE BAR
REV A: 8/29/2012
125 LBS MAX150 LBS MAX
SWINGING WEIGHT
150 LBS MAX
SWINGING WEIGHT
SWING BELT SWING BELT
THIS END
OF SWING
BEAM IS
ATTACHED
TO PLAY SET.
13
