Gorilla Playsets Playmaker - Site Plan Overview

1'-7
2
"
4
"
4'-0"
DECK
DECK
6'-5 7/8"
"
3
8'-0"
14'-
3'-0"
7
16
8'-8
2
1
"
"
1'-7
1
2
3'-1
"
1
2'-
1
8
12'-5 3/8"
Please familiarize yourself with the manual, parts/components and general
construction process of your new playset before getting started.
SITE PLAN:
Playset height: 9 feet - 10 -3/4 inches
Deck height: 4 feet
Swing Beam Height: 7 feet - 2-1/2 inches
Approximate assembly time: 6-8 hours
(6) foot unobstructed safety perimeter around playset recommended
Trapeze
Slide
Swing Belts (2)
Rock Wall
Ladder
Combo
14
