Gorilla 47027 Greyback - Adjust Tether Connecting Seat Section to Platform Section

15
Attach Padded Seat Section
Place the padded seat inside of the top section of the climbing treestand
with the support webbing facing toward the ground.
Attach one webbing section to the support rail on the top section of
the climbing treestand by rst looping the webbing over the rail and
feeding the webbing back through the buckle (FIGURE 21, FIGURE 22,
FIGURE 23).
Adjust the slider buckle for the appropriate padded seat height by
pulling the webbing tight (FIGURE 24).
Repeat steps for the remaining webbing sections.
5.2
5.1
FIGURE 21
FIGURE 20
FIGURE 22 FIGURE 23 FIGURE 24
Adjust the tether length
(so that the climbing bar
is at mid-thigh height)
Climbing bar at
mid-thigh height
Platform
Adjust Tether Connecting Seat Section to Platform Section
The tether acts as an umbilical cord between the seat section and the
platform section.
If control of the platform were to be lost, the platform could fall the
length of the tether. In order for you to regain control of the platform it is
important that the tether length is adjusted properly. While the treestand
is at ground level, enter treestand and position the climbing bar at
mid-thigh height.
Exit treestand and, while on the ground,
adjust the length of the tether so
that the climbing bar can be lifted
to mid-thigh height above the
platform (FIGURE 20).
ALL TETHER LENGTH ADJUSTMENTS MUST
BE MADE AT GROUND LEVEL.
Failure to follow these instructions can result in
serious injury or death.
