10.6
Bungee Your Ankles to the Foot Strap
Wrap the attached bungee strap around the back of your ankles
(FIGURE 32).
Hook the rubber coated hook on the foot strap webbing on the left side
of the left foot strap (FIGURE 33 and FIGURE 34).
This bungee strap is used to keep your feet in the foot straps.
FIGURE 32
FIGURE 33 FIGURE 34
Begin to Ascend (Climb Up)
With the full body harness properly adjusted, sit on the climbing bar on
the top seat section as shown in FIGURE 35.
FIGURE 35 FIGURE 36
10.7
