25
10.11
Secure Platform at Hunting Height
Once you reach your desired hunting height with the platform section,
locate the platform sections retainer straps on both of the pivoting
adjustment arms (FIGURE 41 and FIGURE 42).
FIGURE 41 FIGURE 42
While facing the tree, wrap the retainer straps around the front of the
tree and hook them together using the J-hook and cam buckle (FIGURE
43 and FIGURE 44).
Tighten the straps so they are tight on the front of the tree by pulling the
free strap end through the cam buckle (FIGURE 45).
To release the strap, push the lever on the cam buckle (FIGURE 46).
FIGURE 44
FIGURE 46
FIGURE 43
FIGURE 45
