GPRINTER GP-1124T - Internal and Bottom Components; 2.2.2 Internal Components; 2.2.3 Bottom Components

Internal
<Picture 4>
<Picture 5>
Label paper fixing stand
Label paper supply hub
Ribbon take-up hub
Push button for thermal
print head open
Top cover
The bottom
Power port
Parallel port
Bottom cover with DIP switch
RS-232C serial port
Ethernet port
USB port
Label entrance from
external holder
Note: Picture showing printer port is for GP-1125T.
