Installation of the cylinder head cover
1. Take the NC450 cylinder head cover
sealing ring (1) and the Derbi125 head cover bolt
buffer washer (3), and assemble them on the
designated position of the NC450 cylinder head
cover (2).
2. Take 2 pieces of NC450 cylinder head
cover fixing bolts (4) and 2 pieces of NC450
cylinder head cover fixing bolts (5), assemble the
NC450 cylinder head cover (2) on the cylinder
head, and fasten them.
Tightening torque: 11～13N · .m .
