into the center hole of the main shaft, then
install the clutch push rod (27) into the center
hole of the main shaft, and then install the
thrust bearing (28) and the push rod washer
(29) to the top. on the rod,
4. Install the clutch pressure plate (30), the
clutch pressure plate spring (31), and the
pressure plate screw (32), and use a torque
wrench to fasten the pressure plate screw.
Tightening torque: 8～10N m
Assembly of the starter motor
After smearing oil evenly on the cogging
end of the starter motor, assemble the starter
motor in place, and fasten it with 2 bolts M6×
25, the tightening torque is 11～13N·m.
Installation of the right crankcase cover
1. Install the two positioning pins (1) into
the positioning pin holes of the case body,
remove the old right crankcase gasket (2),
install the new gasket, assemble the right
crankcase cover in place and use 11 bolts M6
×35 tightening, tightening torque: 11～13N
m
2. Install the water pump impeller (3) on
the shaft of the water pump and tighten it. The
tightening torque is 2～4N·m;
3. After installing the water pump cover
gasket (4), assemble the water pump cover (5)
in place and fasten with 2 bolts M6×45 and 2
bolts M6×25.
