2. Install the large starting gear (13),
needle bearing (14) and overrunning clutch
(15) on the right crank.
Notice:
Before installing the starter gear,
evenly apply oil on the inner hole of the
starter gear .
Installation of driving gear
1. Install the driving tooth (16) on the
right crank,
2. Install the drive tooth lock nut washer
(17) on the drive tooth,
3. Apply 3 to 4 threads of thread
tightening glue on the locking nut (18) of the
driving teeth, install it on the right crank and
tighten it.
Tightening torque: (115～125)N•m
Thread fastener name: Loctite 263
Installation of the clutch
1. Install the clutch cover washer (19),
needle bearing (20), clutch cover (21) and
clutch center sleeve washer (22) on the main
shaft;
NOTE: Apply oil evenly to the clutch
needles.
2. First install the clutch center sleeve
assembly (23) and the clutch lock nut washer
(24) on the main shaft, apply 3 to 4 threads of
thread tightening glue to the clutch lock nut
(25), install it on the main shaft and tighten it.
solid;
Notice:
Tightening torque of clutch lock nut:
80～90N m
3. Then install the clutch push rod (26)
