GPX NC450 - Assembly Drawing

Page
14
31
Assembly drawing
1. NC450 piston
2. NC450 piston pin retaining
ring
3. NC450 piston ring assembly
4. NC450 piston pin
5. NC450 cylinder block parts
6. NC450 cylinder block gasket
7. Cylindrical pin φ6×12
8. NC450 chain guide plate
combination
9. NC450 timing chain
combination
