Installation of magneto stator
Fasten the magneto stator assembly (18) to
the left crankcase cover with 2 screws M5×10
(19) and 2 screws M5×40 (20) . Tightening
torque: 7～9N·m .
Installation of the left crankcase
cover
1. Remove the old gasket (21) and install a
new gasket;
2. Install the two positioning pins (22) on the
box body;
3. Assemble the left crankcase cover (23) in
place and fasten it with 2 M6×35 bolts (24) and 6
M6×30 bolts (25). Tightening torque: 11～13 N
m .
Note: One of the M6×30 bolts (26) is
coated with Sanhe glue on the disk, and
inserted into the
flat washer (27), and
inserted into the corresponding position as
shown in the figure
