Startup
14 3A5097C
Fill Siphon Cup
1. Unlatch cup cover and remove from
siphon cup.
2. Fill siphon cup with material.
3. Verify siphon tube is positioned in ideal
location for desired spray orientation. If
adjustment is necessary:
a. Loosen nut, rotate cup cover to
attain desired siphon tube position.
b. Tighten nut.
4. Latch cup cover to siphon cup.
ti30941a
