Technical Specifications
3A5097C 35
Technical Specifications
EDGE II / EDGE II Plus
US Metric
Sprayer
Maximum working air pressure 10 psi 0.07 MPa, 0.7 bar
Maximum working fluid pressure 50 psi 0.35 MPa, 3.5 bar
Air inlet Quick - disconnect
Fluid Inlet
FlexLiner System 5/8-16 UN-2A
Siphon/Remote Cup 3/8-18 npsm
Weight
Edge II / Edge II Plus (gun only) 20 oz. 570 g
FlexLiner System 15 oz. 425 g
Siphon Cup Assembly 17 oz. 480 g
Noise*
Sound pressure 65.0 dBa
Sound power 65.0 dBa
Wetted Materials of Construction
Edge II / Edge II Plus (gun only) stainless steel, aluminum, ultra-high molecular weight
polyethylene (UHMWPE), acetal, fluoroelastomer
FlexLiner System stainless steel, Grilamid, polyethylene, low-density
polyethylene (LDPE)
Siphon Cup stainless steel, brass, zinc-plated carbon steel, aluminum,
polyethylene
Notes
*Sound pressure measured 3 feet (1 meter) from equipment. Sound power
measured per ISO-3744.
