Graco 17R236 - Startup; Fill Flexliner System

Startup
12 3A5097C
Startup
Fill FlexLiner System
1. Disconnect gun from FlexLiner System.
2. Loosen ring from cup. Remove cover
and ring from cup. Verify FlexLiner
remains in cup upon removal of cover
and ring.
3. Fill FlexLiner with material to “MAX FILL”
line. Clean threads and sealing surfaces
of FlexLiner System.
ti30706a
ti30707a
ti30708a
