Graco 232-504 - Page 21

308-550 21
Service
04708
04621
03982
Fig. 13
1
3
4
2
24
104
403*
401*
24
24 104 401*
403*
105
19 402*
Cutaway V iew , with Diaphragms in Place Cutaway V iew , with Diaphragms Removed
1
Lips face out of housing (1).
Air Side must face center housing (1).
1
Grease.
Used on Models with T eflon diaphragms only .
1
1
105
3
3
2
2 4
2 4
23
5
Apply medium-strength (blue) Loctite  or equivalent.
T orque to 160 to 200 in-lb (18.1 to 22.6 N-m) at 100 rpm
maximum.
5
5
