Graco 232-504 - Repair Kit Matrix

 
Repair Kit Matrix
For Husky 2150 Polypropylene and Kynar Pumps, Series A
Repair Kits may be ordered separately . T o repair the air valve, order Part No. 236–273 (see page 27). Parts
included in the Air V alve Repair Kit are marked with a symbol in the parts list, for example (4 ).
T o repair your pump, select the six digits which describe your pump from the following matrix, working from left to
right. The first digit is always D , the second digit is always 0 (zero), and the third is always G . The remaining three
digits define the materials of construction. Parts included in the kit are marked with an asterisk in the parts list, for
example (201*). For example, if your pump has polypropylene seats, T eflon balls, and T eflon diaphragms, order
Repair Kit D 0 G – 9 1 1. If you only need to repair certain parts (for example, the diaphragms), use the 0 (null)
digits for the seats and balls, and order Repair Kit D 0 G – 0 0 1. The digits in the matrix do not correspond to
the ref. nos. in the parts drawing and lists on pages 27 and 28.
Diaphragm
Pump
Null
Fluid Section
Material – Seats Balls Diaphragms
D (for all pumps) 0 (for all pumps) G (Plastic) – 0 (null) 0 (null) 0 (null)
– 1 (not used) 1 (T eflon) 1 (T eflon)
– 2 (not used) 2 (Acetal) 2 (not used)
– 3 (316 SST) 3 (not used) 3 (not used)
– 4 (17–4 PH SST) 4 (440C SST) 4 (not used)
– 5 (Hytrel) 5 (Hytrel) 5 (Hytrel)
– 6 (Santoprene ) 6 (Santoprene ) 6 (Santoprene )
– 7 (not used) 7 (not used) 7 (not used)
– 8 (not used) 8 (V iton) 8 (V iton)
– 9 (polypropylene)
– A (Kynar)
