Graco 232-504 - Diaphragm Parts List (Matrix Column 6); Ball Parts List (Matrix Column 5)

 
Parts
Seat Parts List (Matrix Column 4)
Digit
Ref.
No.
Part No. Description Qty
3 201* 189–288 SEAT ; 316 stainless steel 4
202* 112–358 O-RING; Teflon 4
4 201* 189–289 SEAT ; 17–4 stainless
steel
4
202* 112–358 O-RING; Teflon 4
5 201* 189–292 SEAT; Hytrel 4
202 None Not Used 0
6 201* 189–290 SEAT ; Santoprene 4
202* 112–358 O-RING; Teflon 4
9 201* 189–291 SEAT ; polypropylene 4
202* 112–358 O-RING; Teflon 4
A 201* 189–745 SEAT; Kynar 4
202* 112–358 O-RING; Teflon 4
Ball Parts List (Matrix Column 5)
Digit
Ref.
No.
Part No. Description Qty
1 301* 112–359 BALL; T eflon 4
2 301* 112–363 BALL; acetal 4
4 301* 112–360 BALL; 440C stainless
steel
4
5 301* 112–745 BALL; Hytrel 4
6 301* 112–361 BALL; Santoprene 4
8 301* 112–362 BALL; V iton 4
Diaphragm Parts List (Matrix Column 6)
Digit
Ref.
No.
Part No. Description Qty
1 401* 189–296 DIAPHRAGM, backup;
Santoprene
2
402* 112–181 P ACKING, u-cup; nitrile 2
403* 189–294 DIAPHRAGM; Teflon 2
5 401* 189–295 DIAPHRAGM; Hytrel 2
402* 112–181 P ACKING, u-cup; nitrile 2
6 401* 189–296 DIAPHRAGM; Santo-
prene
2
402* 112–181 P ACKING, u-cup; nitrile 2
8 401* 189–297 DIAPHRAGM; Viton 2
402* 112–181 P ACKING, u-cup; nitrile 2
