Models

3A0732U 3

Models

Package Series Ratio

Maximum Fluid

Working Pressure

psi (MPa, bar)

Package Type Gun Mounting Material

24F150 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Wall Plated Steel

24F151 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Stand Plated Steel

24F152 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Wall Stainless Steel

24F153 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Stand Stainless Steel

24F154 B 30:1 3000 (20.7, 207) Airless PerformAA 50 Airless Wall Plated Steel

24F155 B 30:1 3000 (20.7, 207) Airless PerformAA 50 Airless Stand Plated Steel

24F156 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Wall Plated Steel

24F157 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Stand Plated Steel

24F158 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Wall Stainless Steel

24F159 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Stand Stainless Steel

24N548* A 30:1 3000 (20.7, 207) WB3000 ----- ----- Stainless Steel

24W281 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Stand Plated Steel

24W283 B 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 Stand Stainless Steel

24W285 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Stand Plated Steel

24W287 B 30:1 3000 (20.7, 207) Air-assisted PerformAA 50 Stand Stainless Steel

24X311** A 15:1 1500 (10.3, 103) Air-assisted ----- Wall Plated Steel

24J250 A 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 WL Wall Plated Steel,

u-cup

24J251 A 15:1 1500 (10.3, 103) Air-assisted PerformAA 15 WL Stand Plated Steel,

u-cup

* Part No. 24N548 is used as a supply pump in the WB3000 Waterborne Isolation System. It includes a pump

bracket and items 7-19, 21, 23, and 28-42 on page 27. See manual 3A2497 for warnings and instructions for a

waterborne system.

** Part No. 24X311 is used as a solvent flush pump in the M2K system. See manual 333309 for warnings and

instructions for a solvent flush pump.
